The difference between the titanium globe valve and the gate valve is mainly reflected in the following aspects:
Flow & Functions :
Titanium globe valve: not only can it be used as a cut-off, but also can be used to regulate and control the pressure flow. In the process of use, it is generally not necessary to open it all
Titanium gate valves: often used for isolation, and generally need to be fully opened or closed during use.
Resistance to Fluids :
Titanium globe valve: the flow resistance to the fluid is large, and the resistance coefficient is generally between 3.5 and 4.51
Titanium gate valve: the flow resistance to the fluid is small, and the resistance coefficient is generally between 0.08 and 0.12.
Installation :
Globe valve: The medium generally flows from top to bottom from the valve core, and there are regulations on the direction of the inlet and outlet, it needs to be installed in strict accordance with the direction marked by the arrow of the valve body
Gate valve: the flow direction is the same as that of entering from above or below, and there is no requirement for the inlet and outlet directions.
Disc structure :
Titanium globe valve: the disc remains parallel to the fluid, and there is no distinction between open rod and dark rod.
Titanium gate valve: The disc is a gate plate, which is perpendicular to the direction of the fluid, and is divided into open rod and dark rod.
How it works :
Titanium globe valve: The handwheel and stem work together to rotate and rise.
Titanium gate valve: only the handwheel will rotate, and the valve stem will only do the upward action.
Shape & Dimensions :
Titanium globe valve: short in height and long in length.
Titanium gate valve: the structure is relatively complex, the height is higher under the same caliber, and there are open rods and dark rods
Titanium globe and gate valves differ significantly in terms of flow and function, resistance to fluids, installation, disc structure, operating principle, and shape and size. These differences make globe and gate valves play different roles in their respective applications.
